Project Description

Large format sensors are here to stay. The ARRI LF, the RED Monstro, the SONY Venice, and the Panavision DXL 2 are the most recent additions to the the growing list of large format cameras. The larger sensors deliver a more organic look with an interesting bokeh due to the extremely shallow depth of field, but to get the best performance from these sensors, lenses with image circles of at least 50 mm are necessary.

The RAPTOR lenses featuring full frame coverage, 1:1 magnification, consistent T-Stop T 2.9 as well as robust and durable professional cine mechanics.

More than 50mm Image Circle

The lenses cover every sensor up to Vista Vision and beyond. They are literally future proofed for new cameras.

Universal Mount System

With an exclusive Univeral Mount System we ensure that the lenses can be used on most cameras. Do not worry if you use EF, PL, Sony E cameras, the UMS will be easy to switch and keep you highly versatile.

Close Focus

Depending on the focal length you have different minimum close focus ranges.

60mm – 19cm

100mm – 31.2cm

150mm – 38cm

APO Color Correction

Designed with a special apochromatic (APO) lens element, for a better correction of chromatic and spherical aberrations. Better color accuracy by design.

1:1 Magnification

These lenses have an amazing 1:1 magnification, which will enable you to see the smallest details in the macro world like never before.

High End Technical Specifications

Aperture: T2.9-T22
Focus Rotation: 300°
Iris Rotation: 70°
Iris Leaves: 9
Length (Flange to front) : 60mm 10.6cm – 100mm/150mm 15cm
Front Diameter: 95cm

Weight: 60mm 1.15kg – 100mm 1.55kg – 150mm 1.76kg
