Project Description

Canon Cinema EOS C300 Mark II Camcorder Body (PL Lens Mount)

Image Sensor
Type CMOS
Sensor Size Super 35
24.6 x 13.8mm effective size / 6.4 x 6.4µm pixel pitch
Effective Pixels Approx. 8.85 Mp (4096 x 2160)
Approx. 8.29 MP (3840 x 2160
Total Pixels Approx. 9.84 Mp (4206 x 2340)
Scanning System Progressive
Filter RGB primary color filter (Bayer array)
Processor 2 x DIGIC DV 5
Lens System
Lens Mount PL
Built-In ND Filters Standard: 2, 4, 6 Stops
Expanded: 2, 4, 6, 8, 10 Stops
Exposure and Metering
Exposure Modes Manual
Gain Normal: -2 dB to 44 dB
Expanded: -6 to 54 dB
ISO Range Standard: 160 to 25,600
Expanded: 100 to 102,400
Shutter Modes Off, Speed, Angle, Slow Shutter, Clear Scan
Shutter Speed 59.94i/59.94p: 1/60 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/4, 1/8, 1/15, 1/30; CS: 59.94 – 250.70 Hz
29.97p: 1/30 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/4, 1/8, 1/15; CS: 29.97 – 250.70 Hz
23.98p/24p: 1/24 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/3, 1/6, 1/12; CS: 23.97 – 250.70 Hz
50i/50p: 1/50 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/3, 1/6, 1/12 1/25; CS: 50.00 – 250.70 Hz
25p: 1/25 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/3, 1/6, 1/12; CS: 25.00 – 250.70 Hz
Shutter Angle 59.94i/59.94p: 360, 240, 216, 180, 120, 90, 60, 45, 30, 22.5, 15, 11.25
29.97p: 360, 240, 216, 180, 120, 108, 90, 60, 45, 30, 22.5, 15, 11.25
23.98p/24p: 360, 345.6, 288, 240, 180, 172.8, 144, 120, 90, 86.4, 72, 60, 45, 30, 22.5, 15, 11.25
50i/50p: 360, 300, 240, 180, 150, 120, 90, 60, 45, 30, 22.50, 15, 11.25
25p: 360, 300, 240, 180, 150, 120, 90, 75, 60, 45, 30, 22.50, 15, 11.25
Focus Control
Focus Modes Manual /
Auto
Autofocus System Dual Pixel CMOS
Video
Signal System NTSC/PAL
Compression XF AVC – H.264 in MXF wrapper
Bit Rates Intra: 410 / 225 / 210 / 110 Mbps
LongGOP: 50 Mbps
LongGOP (Proxy): 35 or 24 Mbps (for proxy recording on SD cards)
Color Space 4:2:2 (YCC) 10-bit
4:4:4 (RGB) 12- or 10-bit*

*Only available with 2048 x 1080 or 1920 x 1080 at 29.97p, 23.98p, 25.00p, and 24.00p

System Frequency Selection 59.94 Hz,br> 50 Hz
24 Hz
Video Format XF AVC
Video compression Formats: MPEG-4 AVC/H.264
CFast Card
Intraframe Recording Resolution : 4096×2160/3840×2160, 2048×1080, 1920×1080
Signal Configuration : Y CC422/RG84 44 (10/12-bit)(Only with 2048×1080 or 1920×1080; 29.97p, 23.98p, 25p and 24p)
LongGOP Resolution: 2048 x 1080/1920 x 1080
Signal: YCC422 10-bit

SD Card
LongGOP Recording Only (Proxy)Resolution : 2048 x 1080 / 1920 x 1080
Signal: YCC420 8-bit

Photo: JPEGResolution : 2048 x 1080, 1920 x 1080

Recording Media CFast Card: 2 x slots
SD Card: 1 x slot
Frame Rate 59.94 Hz Mode
59.94i/p, 29.97p, 23.98p

50 Hz Mode
50i/p, 25p

24 Hz Mode
24p

Audio
Audio Recording Linear PCM; 2-channel; 16/24-bit; 48 kHz 4-ch
Built-In Microphone None
Audio Inputs 2 x XLR (auto and manual level settings), switchable between mic/line
1 x 3.5mm microphone jack
Channel Selection 2-channel recording
XLR Mic Trimming -12, -6, 0, or +12 dB
Limiter Available
Recording Levels -∞ to +18 dB
Phantom Power +48V
Headphone Output Level 16 settings; volume is muted at lowest setting
Tone 1 KHz tone available; -12, -18, or -20 dB
Monitor
Type Rotating color LCD
4″ (10.16 cm) diagonal
1,230,000 dots
Aspect Ratio 16:9
Viewfinder
Type 0.46″ (1.32 cm) diagonal, color
1,170,000 dots
Angle Adjustment Up and down 60°
Features
White Balance Manual
2 Custom (2000 to 15,000K)
Daylight (5400K)
Tungsten (3200K)
Exposure & Focus Aids Peaking (2 types), Zebra Pattern, Magnify, Edge Monitor Focus Assist, Black and White Mode

Note: Zebra can be output via the SDI or HDMI jack (HD only)

Playback Index Displays: Index Display, Normal, “OK Mark” Index, “Check Mark” Index, “Shot Mark” Index, Expand Index, Photo Index
Clip Playback: Forward Search (5x, 15x, 60x), Reverse Search (5x, 15x, 60x), Forward Frame Advance, Reverse Frame Advance, Record Review, Clip Jump (Forward and Backward), Skip Playback
Playback Functions: Inter-Media Copy (Single Clip, All Clips, Last Clip); Clip Delete (Single Clip, All Clips, Last Clip)
Still Image Playback: Index, Single Playback, Erasure, Protect
Color Bars Color bars compliant with SMPTE, EBU, or ARIB standards can be selected
Inputs/Outputs
SDI 3G-SDI: 2x BNC (output)
HDMI Output 1 x Type A
Genlock BNC (input only)
Adjustment Range: -1023 to +1023
Time Code I/O 1 x BNC
Drop Frame (DF) and Non-Drop Frame (NDF)
Time Code Modes: Regen, Record Run, Free Run, and External Source

Note: Drop Frame works with NTSC modes only and is not available in 24p

Audio Input Terminals 2 x Balanced 3-pin XLR (Mic Level, Mic Level with phantom power and Line Level) 1 x 3.5mm microphone jack
Headphone Connector 3.5mm stereo mini-jack
Remote 2.5mm LANC-compatible terminal
Wi-Fi WFT terminal for compatible Wi-Fi accessory
General
Power Supply 14.4 VDC (battery pack), 16.7 VDC (DC input)
Dimensions (W x H x D) Approx. 5.9 x 7.2 x 7.2″ / 149 x 183 x 183 mm (without grip)
7.5 x 7.2 x 7.4″ / 19.1 x 18.3 x 18.8 cm (with grip)
